AMC SKU #: EMEVSE1-A-H-J
Manufacturer Model #: EMEVSE1-A-H-J
Minimum Order: 1
Swift and efficient Level 2 charging for all-electric vehicle models. Maximum power of up to 48 amps hardwired.
Input Voltage: 208/240VAC 50/60Hz
Power Charge
11.5kW (240V/48A)
10kW (208V/48A)
9.6kW (240V/40A)
8.3kW (208V/40A)
Required Breaker
Dedicated 50A+ dual pole for 40A
Dedicated 60A+ dual pole for 48A
Connector
25’ cable SAE J1772 connector
Enclosure
Enclosure Watertight NEMA Type 4 indoor/outdoor
Power Wiring
Hardwired (up to 48A)
Temperature Range
-22°F to 122°F (-30°C to 50°C)
Dimensions
12.5" H x 9.0" W x 3.3" D
| Manufacturer Model | EMEVSE1-A-H-J |
|---|---|
| ENERGY STAR® Certified | Yes |
| UPC | 850019360066 |
| Manufacturer Warranty (Years) | 1 |
| Country of Origin | India |
